US 2-PIN POWER SUPPLY, 250W

TECHNICAL DATA

GENERAL

Input voltage

100 – 240 VAC

Input frequency

50 / 60 Hz

Input current

3.9 A

Input connector

US (Type A)

Output voltage

54 VDC

Output current

4.62 A

Output connector

2-pin, with cord end terminals

Weight

910 g

ADDITIONAL

Input voltage range

90 – 264 VAC

Input frequency range

47 – 63 Hz

Maximum input inrush current

60 A

Output voltage maximum deviation

51.3 – 56.7 VDC

Short circuit protection

✓

HIPOT (dielectric withstand test)

Primary to Secondary: 1500 VAC

Certification

Safety: IEC62368-1 (CB Scheme), UL 62368-1:2014, CAN/CSA-C22.2 No. 62368-1-14

EMC: FCC Part 15:2019 / ANSI C63.4:2014
